Part Number: ANDW-EW132-140 Category Brand:

Andrew EW132 – 140, HELIAX Standard Elliptical Waveguide 14.0 14.5 GHz, black PE jacket

SUBMIT RFQ FOR PRICING

Construction Materials
Jacket Material PE
Conductor Material Corrugated copper
Jacket Color Black

Dimensions
Cable Volume 167.0 L/km | 1.8 ft?/kft
Cable Weight 0.33 kg/m | 0.22 lb/ft
Diameter Over Jacket (E Plane) 24.40 mm | 0.96 in
Diameter Over Jacket (H Plane) 15.50 mm | 0.61 in

Electrical Specifications
Operating Frequency Band 14.0 ? 14.5 GHz
eTE11 Mode Cutoff 9.220 GHz
Group Delay 131 ns/100 ft @ 14.700 GHz
428 ns/100 m @ 14.700 GHz
